Demultiplexer and Multiplexer , 1:4, 1:8, 1:12 , 1GHz, 50Ohm, wired ready for connection without user interface. The functionality of the outputs can be chosen individually by the customer. 19“, 1HU
DEV 121x
De-/Multiplexer
Demultiplexer and Multiplexer, 1:4, 1:8, 1:12 , DC-2,5GHz, 50Ohm, wired ready for connection without user interface. The functionality of the outputs can be chosen individually by the customer. 19“, 1HU
DEV 1221/1222
SPDT Switch
SPDT Switch, single and dual channel version, 2:1 and 1:2, 50Ohm, 2,5GHz, redundant power supplies from two different primary lines, wired ready for connection with local user interface, RS232 and Digital Interface, 19“, 1HU
DEV 1258
De-/Multiplexer
Demultiplexer and Multiplexer 8:1 for automatic signal distribution systems to be applied as a redundancy switch, DC-2,5GHz, 50Ohm and 75Ohm versions, RS232, Ethernet and SNMP, 19“, 1HU
DEV 1400
RF-µW -Switching System
RF-µW Switching Systems from 3-18GHz for C-, CX-, X- or Ku-Band, 50Ohm, modular architecture for different functionalities: Receive/Distributing Matrix (2:2 to 2:8), Transmit/Combining Matrix (2:2 to 8:2) and Double Redundancy Switch (2+1 to 8+1), Ethernet with SNMP, 19”, 3HU
DEV 1520/xx
L-Band Sensing Switch
L-Band DPST Sensing Switch 2:1, 4-16 channel version, 950MHz-2150MHz, 75Ohm, automatic measuring and switching to the redundancy input when signal below threshold, redundant power supplies from two different primary lines, RS232, Ethernet with SNMP, 19“, 3HU
DEV 1711/xx
Multichannel On/Off Switch
Multichannel On/Off Switch, 47MHz-862MHz, 75Ohm, BNC, terminated on both sides, 8, 16, 24 or 32 channels TV-Band, without integrated Combiner, redundant power supplies from two different primary lines, 19", 3HU
DEV 171x
De-/Multiplexer
Demultiplexer and Multiplexer, 1:4, 1:8, 1:12 – 1:64, 47MHz-862MHz and 950MHz-2150MHz, 75Ohm, wired ready for connection, user interface as Web-Interface, redundant power supplies from two different primary lines. The functionality of the outputs can be chosen individually by the customer. RS232 and Ethernet, 19“, 1HU or 3HU
DEV 1724
Four Channel Switch
Four Channel Switch for ASI data stream 2:1, 30MHz-862MHz, 75Ohm, redundant power supplies from two different primary lines, wired ready for connection without local user interface; RS232 and Ethernet, 19“, 1HU
DEV 1911/1911V/xx
Multichannel On/Off Switch with integrated Combiner
Multichannel On/Off Switch, 47MHz-862MHz, 75Ohm, BNC, terminated on both sides, 8, 16, 24 or 32 channels (x inputs, 1 output) TV Band, with integrated Combiner and Amplifier, redundant power supplies from two different primary lines, RS232, Ethernet and SNMP, 19", 3HU
DEV 1951
Universal Switch Chassis
Single and Dual Channel Chassis for various switch cards, frequency band and impedance according to configuration of cards (DPST card with monitoring port, ASI redundancy card, SPDT Ultra Broad Band card with SMA- or N-Connectors, DPST Sensing Switch card with measuring of RF signal level and monitoring of preset threshold), redundant power supplies from two different primary power lines, RS232, Ethernet and SNMP, with built-in Web-Interface, 19“, 1HU,
DEV 1991B-E/n+1
Redundancy Switch for CATV and L-Band
Redundancy Switch n+1 (from 2+1 to 64+1), single and double version, DC–2150MHz, 50Ohm and 75Ohm, wired ready for connection with MIMIC user interface 8+1 (standard), redundant power supplies from two different primary lines, RS232, Ethernet and SNMP, 19“, 3HU
DEV 1995/1996
Distributing Matrix for CATV and L-Band
Distributing Matrix, 47MHz-862MHz and 950MHz-2150MHz, n:8 or n:m, can be realised up to 128 x 128, redundant power supplies from two different primary power lines, RS232, Ethernet and SNMP, built-in Web-Interface, 19“, HU according to configuration
RF Splitters and Combiners
Photo Name of Product Technical Description PDF
DEV 2180
L-Band DA Chassis
L-Band Distribution Amplifier Chassis, 950MHz-2150MHz, 50Ohm and 75Ohm versions and combinations 50-75Ohm and 75-50Ohm for integration of multiple DAs (up to 12 x 1:8 or up to 8 x 1:16 Dividers as well as Matrix switches with receiver selectable output ports e.g. 4:11, 4:22 up to 4:44 in a space saving Chassis, bias current monitoring as well as RF sensing on request, redundant power supplies from two different primary lines, 19”, 4HU
DEV 2182C/2183B/2185
L-Band Distribution Amplifier
L-Band Distribution Amplifier 1:8, 2x 1:8 and 1:16, 950MHz-2150MHz, 50Ohm and 75Ohm versions and combinations 50-75Ohm and 75-50Ohm, with remote alarming function, 0dB monitoring output at the front side, redundant power supplies from two different primary lines, remote alarming function, 19“, 1HU
DEV 2216
L-Band Combiner
L-Band Combiner 16:1, 950MHz-2150MHz, 50Ohm and 75Ohm, 0dB monitoring output at the front side, redundant power supplies from two different primary lines, remote alarming function, 19“, 1HU
DEV 2316
CATV-Band Combiner (active)
CATV-Band Combiner active, 16:1, 47MHz-862MHz, 75Ohm, F-Connectors, a monitoring port at the front side carries the output signal at a 20dB reduced level, redundant amplifiers and redundant power supplies from two different primary lines, slope and gain adjustable from the front side, with remote alarming function, 19“, 1HU
DEV 2404/2408/2416
CATV-Band Combiner (passive)
CATV-Band Combiner, passive, 4:1, 8:1 and 16:1, 47MHz-862MHz, 75Ohm, a monitoring port at the front side carries the output signal at a 20dB reduced level, 19“, 1HU
DEV 2708/2716
CATV-Band Distribution Amplifier (active)
CATV-Band Distribution Amplifier 1:8 and 1:16, 47MHz - 862MHz, 75Ohm, F-Connectors, a monitoring port at the front side carries the output signal at a 20dB reduced level, redundant amplifiers and redundant power supplies from two different primary lines, slope and gain adjustable from the front side, remote alarming function, 19“, 1HU
DEV 2744
CATV-Multistream Router (active)
CATV-Band Multistream Router 4:4, 47MHz-862MHz, 75Ohm, F-Connectors, a monitoring port at the front side carries the output signal at a 20dB reduced level, redundant amplifiers and redundant power supplies from two different primary lines, slope and gain adjustable from the front side, remote alarming function, 19“, 1HU
DEV 2910
Reverse Communication Network
CATV-Reverse Communication Network for combining and distribution of signals, 10MHz-70MHz, Combiners, Dividers up to 862MHz are available, 75Ohm, BNC-Connectors. The system can be configured with passive combiners and dividers and distribution amplifiers according to customer requirements, redundant power supplies from two different primary lines, remote alarming function, 19", 3HU
